Co-Axial Cables
Product Details:
X
Product Description
Co-Axila Cables
V-Marc COAXIAL CABLE are widely used today for high-tech multi-channel cable t.v. network in high rise buildings, offices, hotels, hospitals, residential complexes etc. has gained confidence among viewers by delivering quality transmission of TRUE PICTURE & TRUE SOUND. V-MARC COAXIAL CABLE are made of high conductivity electrolytic grade annealed bare solid copper conductor with special grade polyethylene / gas injected physical form pe dielectric. Bonded aluminium foil screening in combination with tinned copper braiding ensures low loss in signal quality & clear pictures. This double screening provides better attenuation values compared with cable with single screen. After screening, the outer jacket is extruded with special grade PVC which is U.V. and abrasion resistant. Excellent adhesion of insulant to conductor, as well as bonded aluminium foil to dielectric does not allow the moisture to enter the cable. This make is ideal for use in tropical condition.
Salient Features
V-Marc COAXIAL CABLE are widely used today for high-tech multi-channel cable t.v. network in high rise buildings, offices, hotels, hospitals, residential complexes etc. has gained confidence among viewers by delivering quality transmission of TRUE PICTURE & TRUE SOUND. V-MARC COAXIAL CABLE are made of high conductivity electrolytic grade annealed bare solid copper conductor with special grade polyethylene / gas injected physical form pe dielectric. Bonded aluminium foil screening in combination with tinned copper braiding ensures low loss in signal quality & clear pictures. This double screening provides better attenuation values compared with cable with single screen. After screening, the outer jacket is extruded with special grade PVC which is U.V. and abrasion resistant. Excellent adhesion of insulant to conductor, as well as bonded aluminium foil to dielectric does not allow the moisture to enter the cable. This make is ideal for use in tropical condition.
Salient Features
- Low attenuation values
- Minimum structural return loss
- Low loss in signal quality
- High band width
- Moisture proof
- Excellent adhesion
| Construction Parameters | Unit | RG 59 F | RG 6 F | RG 11 F |
| Inner Conductor Nom. Dia. | MM | Solid Bare Copper 0.8 | Solid Bare Copper 1.02 | Solid Bare Copper 1.63 |
| Dielectric Nom. Dia. | MM | Foam PE 3.55 | Foam PE 4.57 | Foam PE 7.11 |
| Outer Conductor 1st Shield 2nd Shield Min. Coverage | % | Bonded AI Tape ATC Braid 60 | Bonded AI Tape ATC Braid 60 | Bonded AI Tape ATC Braid 60 |
| Jacket Nom. Dia. | MM | PVC (Black) 6.2 | PVC (Black) 7.2 | PVC (Black) 10.5 |
| Bending Radius (Min.) | MM | 65 | 65 | 75 |
| Electrical Parameters | Unit | RG 59 F | RG 6 F | RG 11 F |
| Inner Conductor Max. Resi. AT 20°C | OHM / 100 Mtrs. | 3.55 | 2.13 | 0.84 |
| Nominal Capacitance | PF / Mtr. | 53 | 53 | 53 |
| Characteristics Impedance | OHM | 75 | 75 | 75 |
| Nominal Velocity Ratio | % | 85 | 85 | 85 |
| Attenuation dB 100 Mtrs. (20°C) | Frequency | RG 59 F | RG 6 F | RG 11 F |
| 211 | MHz | 12.47 | 9.50 | 6.23 |
| 250 | MHz | 13.45 | 10.50 | 6.72 |
| 300 | MHz | 14.60 | 11.50 | 7.38 |
| 350 | MHz | 15.75 | 12.45 | 7.94 |
| 400 | MHz | 16.73 | 13.30 | 8.53 |
| 450 | MHz | 17.72 | 14.35 | 9.02 |
| 500 | MHz | 18.70 | 14.95 | 9.51 |
| 550 | MHz | 19.52 | 15.70 | 9.97 |
| 600 | MHz | 20.34 | 16.45 | 10.43 |
| 750 | MHz | 22.87 | 18.35 | 11.97 |
| 865 | MHz | 24.67 | 19.95 | 13.05 |
| 1000 | MHz | 26.64 | 21.45 | 14.27 |
